Roadtec SX-5 Soil Stabilizer/Reclaimer

Overview

The clean running 513 horsepower SX-5 is ideal for soil stabilization and light reclamation.

Whether preparing a new surface or recycling existing road surfaces, the ability to cut up to 96" wide and 16" deep makes the SX-5 ideal for soil stabilization and road rehabilitation. Weight is evenly distributed between two axles and balanced over the cutter. Even distribution enables optimal controlled power. Four drive pumps deliver 100% traction control, enabling the SX-5 to perform consistently in the most challenging environments.

Applications

  • Roadtec SX-6 Soil Stabilization

    Soil Stabilization

    Soil Stabilization is essential when subgrade soils lack sufficient strength to support new pavements and foundations. The existing material is milled, and additives may be integrated to increase bearing capacity.  The enhanced material is graded and compacted to provide a superior quality base for a new road or foundation.

    Learn More
  • Roadtec SX-6 Soil Stabilizer/Reclaimer reclaiming an asphalt surface

    Road Reclamation

    Asphalt Reclamation, also known as Full Depth Reclamation (FDR), is a cost-effective method of pavement rehabilitation. During FDR the full thickness of the asphalt surface and a portion of the underlying base is uniformly graded and pulverized to serve as the base for a new road. Additives such as cement or asphalt emulsion are often incorporated to increase strength. The result is a homogenous layer with improved structural capacity.
    Learn More

Downloads

Features

Specifications

UNITS:
Engine Specifications
Engine MFG Cummins
ModelQSG 12
Max Power283 kW @ 1,900 rpm
Electrical System24v



Engine Specifications
Engine MFG Cummins
ModelQSG 12
Max Power513 hp @ 1,900 rpm
Electrical System24v

Weight & Dimensions
Specifications
Shipping Weight28,722 kg
Operating Length 9,652 mm
Shipping Width2,844 mm
Shipping Height3,500 mm
Wheelbase 5,384 mm




Weight & Dimensions
Specifications
Shipping Weight62,000 lbs
Operating Length 31' 8"
Shipping Width9' 4"
Shipping Height11' 1"
Wheelbase 17' 8"

CapacitiesSpecifications
Hydraulic Tank Capacity340 ltr
Fuel Tank Capacity1,135 ltr



CapacitiesSpecifications
Hydraulic Tank Capacity90 gal
Fuel Tank Capacity300 gal


Cutter SystemSpecifications
Standard Cut Width2,438 mm
Max Cut Depth406 mm
Drum Spacing18.7 mm and 26.5 mm
Cutter SystemSpecifications
Standard Cut Width96"
Max Cut Depth16"
Drum Spacing0.737" and 1.047"
DriveSpecifications
Travel0-10 kph
SteeringJoystick
Turning Radius7010 mm
DriveSpecifications
Travel0-6 mph
SteeringJoystick
Turning Radius23'
