Peterson BTR70 Blower Trailer

Overview

With a Peterson BTR70 Blower Trailer, you can tackle an even wider range of projects, gain productivity, and boost your profitability.

The BTR70 Blower Trailer features the same high capacity delivery system as our popular blower trucks, but with more advantages from a self-contained power unit.

The BTR70 Blower Trailer provides easy change-over for either left or right side material discharge—a crucial function on many jobs, such as for roadway improvements.

These benefits plus the BTR’s lightweight aluminum construction, which yields increased payload capacity, make the BTR70 Blower Trailer a smart investment for your landscape business.

Applications

  • Mulch

    Astec machines can help you create, screen, stack, and deliver your final mulch product. We’ll help you add value to your mulch products and services from your feedstock all the way to delivery.
    Learn More
  • Compost

    Compost is organic matter that has been decomposed and may be made from single source material or blended for specific application performance. Materials used include: garden debris, kitchen scraps, manure, or yard and lawn waste.
    Learn More
  • Playground Chips

    Playground material and engineered wood fiber is can be created with Peterson grinders or chippers and pneumatically delivered with Peterson blower trucks.
    Learn More

Downloads

Features

Specifications

UNITS:
Dimensions Specifications
Operating Length 1219 cm
Operating Width 259 cm
Operating Height 411 cm
Loading Height 396 cm
Box Length 930 cm
Box Height 274 cm
Box Volume, Struck 53 m3
Axle Spacing 124 cm
Tool Box 152 cm
5th Wheel Height 122 cm
Front to 5th Wheel 46 cm
5th Wheel Clearance Radius 162 cm
Center Axle to Bumper 137 cm



DimensionsSpecifications
Operating Length40'
Operating Width8' 6"
Operating Height13' 6"
Loading Height13'
Box Length30' 6"
Box Height9’
Box Volume, Struck70 yds3
Axle Spacing49"
Tool Box60" wide
5th Wheel Height4'
Front to 5th Wheel18"
5th Wheel Clearance Radius64"
Center Axle to Bumper54"



Weight
Weight with Typical Options 12 246 kg
GCVW
2 axle GCVW 34 019 kg
2 axle Payload 13 970 kg
3 axle GCVW 37 330 kg
3 axle Payload 16 782 kg
Weight
Weight with Typical Options 27,000 lbs
GCVW
2 axle GCVW 75,000 lbs
2 axle Payload 30,800 lbs
3 axle GCVW 82,300 lbs
3 axle Payload 37,000 lbs
SuspensionSpecifications
Standard SuspensionAir Ride/Fixed/Tandem
Optional SuspensionsAir Ride/Fixed/Tridem, Air Ride/Slider/Tandem or Tridem
Axle Limit11 340 kg each
Wheels22.5 x 8.25 Polished Aluminum
Tires11R22.5



SuspensionSpecifications
Standard SuspensionAir Ride/Fixed/Tandem
Optional SuspensionsAir Ride/Fixed/Tridem, Air Ride/Slider/Tandem or Tridem
Axle Limit25,000 lbs each
Wheels22.5 x 8.25 Polished Aluminum
Tires11R22.5



Powertrain Specifications
Engine Cat C7.1 Tier IV 168 kW
Fuel Tank Capacity568 L
Hydraulic Tank Capacity 322 L
Water (Dust Suppression) Option 575 L



PowertrainSpecifications
EngineCat C7.1 Tier IV 225 hp
Fuel Tank Capacity150 gal
Hydraulic Tank Capacity85 gal
Water (Dust Suppression) Option200 gal



System Controls
Peterson Adaptive Feed System
Checkmark
Radio Remote
Checkmark



System Controls
Peterson Adaptive Feed System
Checkmark
Radio Remote
Checkmark



Feed System
Floor Aluminum Walking Floor
Wear Liners Aluminum
Blower System
Blower Tri-Lobe®
Blowing Pressure 1.03 bar
Large Capacity Silencer Intake and Discharge



Feed System
Floor Aluminum Walking Floor
Wear Liners Aluminum
Blower System
Blower Tri-Lobe®
Blowing Pressure 15 psi
Large Capacity Silencer Intake and Discharge



Discharge System
Hose Reel powered, holds up to 98 m
Discharge Hose Length 6 m heavy-duty, 91 m standard
Hose Diameter 127 mm, 100 mm
Noise Level with Optional Discharge Silencers 87 db at 7 m



Discharge System
Hose Reel powered, holds up to 320 ft
Discharge Hose Length 20 ft heavy-duty, 300 ft standard
Hose Diameter 5", 4"
Noise Level with Optional Discharge Silencers 87 db at 23‘



Production
Discharge Volume up to 46 m³ per hour
Material Weight up to 1245 kg/m³

Actual output may vary due to moisture content, material density and size, support equipment, terrain variables, and hose diameter'

Production
Discharge Volume up to 60 yds³
Material Weight up to 2,100 lbs/yd³

Actual output may vary due to moisture content, material density and size, support equipment, terrain variables, and hose diameter'
