Peterson 5000H Whole Tree Chipper

Overview

The Peterson 5000H Whole Tree Chipper produces high quality low bark content chips for wood pulp and pellets, processing whole trees in one continuous operation.

Equipped with a large feed throat, the 5000H Whole Tree Chipper can accept up to a 23 inch (56 cm) diameter single tree or multiple smaller stems.

The 5000H Whole Tree Chipper can be configured with a three or four pocket disc, with several optional sheave sizes to make precisely the chip you need. The standard three-pocket disc produces chips from 5⁄8 to 1 1/4 inches (16–32 mm) long, while the optional four-pocket disc produces chips from ½ to 1 inches (13–25 mm) long. Chipping production rates up to 100 tons (90 tonnes) per hour can be achieved depending on chip size and wood characteristics.

Features

Specifications

UNITS:
ChipperSpecificationsSpecifications
Drum Sizeheavy duty, 66" diameterheavy duty, 168 cm diameter
Knife Pockets3 or 4 pockets3 or 4 pockets
Knife SystemsBabbitt or Key Knife™Babbitt or Key Knife™
Discharge Spouthydraulic swivel top or end loadinghydraulic swivel top or end loading
Chip Size1/2" to 1 1/4" 13 to 32 mm
ChipperSpecifications
Drum Sizeheavy duty, 66" diameter
Knife Pockets3 or 4 pockets
Knife SystemsBabbitt or Key Knife™
Discharge Spouthydraulic swivel top or end loading
Chip Size1/2" to 1 1/4"
Dimensions Specifications
Operating Length 1563 cm
Operating Width357 cm
Travel Length 1630 cm
Travel Width 354 cm
Travel Height 411 cm
Frame Length 1,541 cm
Front Ground Clearance 89 cm
Rear Ground Clearance 27 cm
Ground Clearance 33 cm
Axle Spacing 152 cm
Front to 5th Wheel 1271 cm
5th Wheel to Center Axle 1271 cm
5th Wheel to Rear Axle 1,422 cm
5th Wheel Height 126 cm



DimensionsSpecifications
Operating Length51' 3"
Operating Width11' 9"
Travel Length53' 6"
Travel Width11' 7"
Travel Height13' 6"
Frame Length50' 6"
Front Ground Clearance2' 11"
Rear Ground Clearance10"
Ground Clearance13"
Axle Spacing60"
Front to 5th Wheel2' 2"
5th Wheel to Center Axle41' 9"
5th Wheel to Rear Axle46' 8"
5th Wheel Height4' 2"



DimensionsSpecifications
tri-Axle Weight 27 197 kg
5th Wheel Weight 20 412 kg
Total Weight 46 947 kg
DimensionsSpecifications
tri-Axle Weight59,960 lbs
5th Wheel Weight45,000 lbs
Total Weight103,500 lbs
DimensionsSpecifications
Engine

CAT C27 708 kW or 783 kW

CAT C32 708 kW, 839 kW or 895 kW

ClutchPT Tech HPTO 15
Fuel Tank Capacity1420 L
Hydraulic Tank Capacity1211 L
System Controls
Adaptive Control System
Checkmark

Radio Remote
Checkmark

Peterson+ Analytics
Checkmark
DimensionsSpecifications
EngineCATC27 950 hp or 1050 hp
 CAT C32 950 hp 1125 hp  or 1200 hp
ClutchPT Tech HPTO 15
Fuel Tank Capacity375 gal
Hydraulic Tank Capacity320 gal
System Controls
Adaptive Control System
Checkmark

Radio Remote
Checkmark

Peterson+ Analytics
Checkmark
Feed SystemSpecifications
Feed Opening (w x h)133 x 61 cm
Feed Speed Range19 to 52 m/min
Maximum Log Diameter56 cm
Feed Rollsdual with floating top rolls
Lower Feed Rolls7 powered
Log Loader
Lift Capacity5376 kg at 457 cm
Hydraulic Knuckle Boom2-section, 818 cm
Grapple with Heel Rack360° rotation, 107 cm
Controlstwo lever electronic joystick
Enclosed Weatherized Operator's Cabwith Air Conditioner
Feed SystemSpecifications
Feed Opening (w x h)53" w x 24" h
Feed Speed Range64 to 170 ft/min
Maximum Log Diameter23"
Feed Rollsdual with floating top rolls
Lower Feed Rolls7 powered
Log Loader
Lift Capacity11,851 lbs at 15'
Hydraulic Knuckle Boom2-section, 26' 10"
Grapple with Heel Rack360° rotation, 42"
Controlstwo lever electronic joystick
Enclosed Weatherized Operator's Cabwith Air Conditioner
Delimber/Debarker Flail Specifications


Flail Drums single lower and dual floating upper
Drum Diameter 27 cm
Flail Rods/Drum6 per drum
Flail Chain/Drum 78 chains, 8 links each
Drive Type hydrostatic
Flail Speed Range 400 to 700 rpm
End Discharge Bark Mover 305 x 61 cm
Variable Flail Speed adjustable from cab
Delimber/Debarker FlailSpecifications
Flail Drumssingle lower and dual floating upper
Drum Diameter11"
Flail Rods/Drum6 per drum
Flail Chain/Drum78 chains, 8 links each
Drive Typehydrostatic
Flail Speed Range400 to 700 rpm
End Discharge Bark Mover120" x 24"
Variable Flail Speedadjustable from cab
