Pan Feeders

Overview

Astec pan feeders are mechanically driven with a heavy-duty formed deck and are designed to easily replace competitive models.

These feeders feature support springs with guards, bolt-in replaceable liners, re-greaseable bearings and exposed exciters for ease-of-access. Additional options include cone discharge spout, rubber liners and variable frequency drive.

Applications

  • Aggregates

    There are two main classes of aggregates: natural and manufactured. Deleterious material needs to be removed from both classes of aggregates. Processing these materials typically requires various steps including reduction and sizing and also may include dewatering and sorting. Producers can use a variety of crushing, screening, dewatering and conveying equipment to meet their desired specifications.
      Learn More
    • Concrete Recycling

      Concrete is one of the most recycled materials in the world that can be repurposed several times over. Once the existing concrete is demolished or torn up, it needs to be processed for accurate shaping and sizing using a crusher and screen.
        Learn More
      • Construction

        Construction projects today depend on an available supply of quality concrete mix. With the most comprehensive line of concrete production equipment in the industry, Astec is ready to help meet that demand.
        Learn More
      • Construction Aggregates

        Construction aggregate is typically medium or coarse material that is used in construction applications. Processing this material may include reducing its size with a crusher, sizing the crushed material with a screen and conveying the material into different stockpiles.
          Learn More
        • Construction and Demolition (C&D) Recycling

          Construction & Demolition Recycling (C&D) is mixed material associated with construction and demolition. The material could include wood, cardboard, plastic, metal, wire, roofing shingles, concrete and more. By separating and recycling different materials it reduces landfill use and tipping fees, while also producing value-added products.
          Learn More
        • Pioneer® jaw crusher in concrete recycling application

          Crushed Stone

          Crushed stone is a versatile product that can be used in a wide range of applications from construction to road building and even agriculture. Processing this material may include reducing its size with a crusher, sizing the crushed material with a screen and conveying the material into different stockpiles.
            Learn More
          • Roadtec RX-700 cold planer milling asphalt off the road surface into a dump truck

            Recycled Asphalt Pavement

            The asphalt pavement industry has a long history of incorporating reclaimed asphalt pavement (RAP) into new asphalt pavement mix. In fact, Asphalt is America’s most recycled material making the asphalt industry is a leader in the use of recycled materials. Astec has a long history of building world-class tools to allow contractors and producers to collect and utilize this very valuable product.
            Learn More
          • Sand & Gravel

            Sand and gravel are aggregates that are gathered from naturally occurring deposits. These aggregates, when gathered, may contain clays, silts and other deleterious material that needs to be processed out for commercial-grade products. Reduction and sizing can be accomplished with a variety of crushers and screens. Once the material is accurately processed, it can be used for road building, construction materials and a variety of other applications.
              Learn More

            Downloads

            Features

            Specifications

            UNITS:
            Model Width (mm) Length (mm) Exciter Motor Required (kW) Weight (kg)
            3660 910 1,530 1.8 x 2 1,009
            3672 910 1,830 1.8 x 2 1,100
            3684 910 2,130 2.4 x 2 1,168
            3684CD 910 2,130 2.4 x 2 1,200
            4260 1,070 1,530 2.4 x 2 1,077
            4272 1,070 1,830 2.4 x 2 1,145
            4284 1,070 2,130 2.4 x 2 1,213
            4284CD 1,070 2,130 2.4 x 2 1,407
            4884 1,220 2,130 2.4 x 2 1,281
            4884CD 1,220 2,130 3 x 2 1,547
            4896 1,220 2,440 3 x 2 1,349
            4896CD 1,220 2,440 4 x 2 1,574
            5496 1,370 2,440 3 x 2 1,440
            Model Width (in) Length (in) Exciter Motor Required (hp) Weight (lb)
            3660 36 60 2.41 x 2 2,225
            3672 36 72 2.41 x 2 2,425
            3684 36 84 3.22 x 2 2,575
            3684CD 36 84 3.22 x 2 2,646
            4260 42 60 3.22 x 2 2,375
            4272 42 72 3.22 x 2 2,525
            4284 42 84 3.22 x 2 2,675
            4284CD 42 84 3.22 x 2 3,103
            4884 48 84 3.22 x 2 2,825
            4884CD 48 84 4.02 x 2 3,410
            4896 48 96 4.02 x 2 2,975
            4896CD 48 96 5.23 x 2 3,469
            5496 54 96 4.02 x 2 3,175
